Polylux TLQ800 Transformer

Описание

Dry type transformer

IP-20 enclosure in last generation V-0 fireproof polymer box, according to UL94

Safety class I, convertible in class II

Includes LED functioning indicator and electrostatic screen

Full power capacity in every conection

Optional protection fuse

Possibility of tailor-made manufacturing

Angebot anfragen
Um ein kommerzielles Angebot zu erhalten, senden Sie eine Anfrage an info@polylux-transformatoren.de
Charakteristiken
Rating: 800 VA
Input voltage: 230 V±5%
Output voltage: 24-25-26-27 V
Frequency: 50/60 Hz
Protection degree: IP-20
Cooling: ANAN
Ambient temperature: 25ºC
Temperature rise: Class B
Insulation: Class B - 130ºC
Windings: Class HC - 200 ºC
Test voltage: 2,5 kV (1 min, 50 Hz)
Standards: IEC/EN/UNE-EN 61558-1, CE
Mounting: Screws
Weight: 10 kg
Dimensions (AxBxCxDxE): 136x162x180x145x104 mm 6Ø
