Polylux NB40 Transformer
Charakteristiken
Rating: 40 VA
Input voltage: 230/400 V
Output voltage: 12/24 V
Frequency: 50/60 Hz
Protection degree: IP-20
Cooling: AN
Ambient temperature: 30ºC
Temperature rise: Class B
Insulation: Class B - 130ºC
Windings: Class HC - 200 ºC
Test voltage: 4,6 kV (1 min, 50 Hz) pri-sec - 3,2 kV (1 min, 50 Hz) pri-earth - 2,5 kV (1 min, 50 Hz) sec-earth
Standards: IEC/EN/UNE-EN 61558, CE
Mounting: Screws and DIN Rail
Weight: 1,2 kg
Dimensions (AxBxCxDxE): 75x97x84x80x56 mm 6Ø
Input voltage: 230/400 V
Output voltage: 12/24 V
Frequency: 50/60 Hz
Protection degree: IP-20
Cooling: AN
Ambient temperature: 30ºC
Temperature rise: Class B
Insulation: Class B - 130ºC
Windings: Class HC - 200 ºC
Test voltage: 4,6 kV (1 min, 50 Hz) pri-sec - 3,2 kV (1 min, 50 Hz) pri-earth - 2,5 kV (1 min, 50 Hz) sec-earth
Standards: IEC/EN/UNE-EN 61558, CE
Mounting: Screws and DIN Rail
Weight: 1,2 kg
Dimensions (AxBxCxDxE): 75x97x84x80x56 mm 6Ø
