Polylux NB315 Transformer
Charakteristiken
Rating: 315 VA
Input voltage: 230/400/460 V
Output voltage: 12/24 V
Frequency: 50/60 Hz
Protection degree: IP-20
Cooling: AN
Ambient temperature: 30ºC
Temperature rise: Class B
Insulation: Class B - 130ºC
Windings: Class HC - 200 ºC
Test voltage: 4,6 kV (1 min, 50 Hz) pri-sec 3,2 kV (1 min, 50 Hz) pri-earth 2,5 kV (1 min, 50 Hz) sec-earth
Standards: IEC/EN/UNE-EN 61558, CE
Mounting: Screws
Weight: 4,7 kg
Dimensions (AxBxCxDxE): 108x124x124x106x89 mm 6Ø
Input voltage: 230/400/460 V
Output voltage: 12/24 V
Frequency: 50/60 Hz
Protection degree: IP-20
Cooling: AN
Ambient temperature: 30ºC
Temperature rise: Class B
Insulation: Class B - 130ºC
Windings: Class HC - 200 ºC
Test voltage: 4,6 kV (1 min, 50 Hz) pri-sec 3,2 kV (1 min, 50 Hz) pri-earth 2,5 kV (1 min, 50 Hz) sec-earth
Standards: IEC/EN/UNE-EN 61558, CE
Mounting: Screws
Weight: 4,7 kg
Dimensions (AxBxCxDxE): 108x124x124x106x89 mm 6Ø
